Plastic Ball Chain
|
Side Brackets
|
Max Width (mm)
2,000 |
Max Height (mm)
3,000 |
Acceptable Load
2.6 kg |
|---|---|---|---|---|---|
|
Set Bar |
|
Series
|
Operation Type
|
Operation Type
|
Max Width (mm)
|
Max Height (mm)
|
Acceptable Load
|
||
|---|---|---|---|---|---|---|---|
|
LEX- TSRT1
|
|
T1-1029B
|
Plastic Ball Chain
|
Side Bracket
|
2,000
|
3,000
|
2.7kg
|
|
Set Bar
|
|||||||
|
LEX- TSRT1-1
|
|
T1-1029S
|
Spring Drive
|
Set Bar
|
2,000
|
3,000
|
1.8kg
|
|
LEX-TSMY01
|
|
Mytec 01 Loop
|
Metal Ball Chain
|
Side Bracket
|
2,700
|
3,000
|
3.7kg
|
|
Set Bar
|
|||||||
|
Plastic Ball Chain (Option)
|
Set Bar
|
3.2kg
|
|||||
|
LEX-TSMY02
|
|
Mytec 01
|
Spring Drive
|
Side Bracket
|
2,000
|
3,000
|
1.8kg
|
|
Set Bar
|
|||||||
** need to use 46mm dia. pipe
|
Option Type
|
Mytec01 Loop
|
Mytec01
|
||
|---|---|---|---|---|
|
Side Bracket
|
Set Bar
|
Side Bracket
|
Set Bar
|
|
|
Top Box Type |
✔
|
|
✔
|
|
|
Side Frame Type |
✔
|
✔
|
|
|
|
Top Box Type + Side Frame Type |
✔
|
|
|
|
|
Guide Wire Type |
✔
|
✔
|
✔
|
✔
|
|
Top Box + Guide Wire Type |
✔
|
|
✔
|
|
|
Link Type |
✔
|
|
|
|
|
Double Type |
✔
|
|
|
|
|
Link Double Type |
✔
|
|
|
|
** the allowable sizes are depend on the option type.
|
|
Max. Width
(mm) |
Max. Height
(mm) |
Max. Area
|
Bracket Type
|
Motor Spec.
|
Slope
|
Black Out
|
|||
|---|---|---|---|---|---|---|---|---|---|---|
|
Side Bracket
|
Side Bar
|
Torque
|
RMP
|
|||||||
|
Mytec AT-K220
|
|
2,400
|
3,000
|
-
|
|
✔
|
-
|
21 rpm
|
|
|
|
ATF35RB
|
|
2,000
|
4,500
|
9m 3
|
✔
|
✔
|
3 Nm
|
23.5 rpm*
|
✔
|
✔
|
|
ATF45RB
|
|
2,500
|
5,000
|
10m 3
|
✔
|
-
|
5 Nm
|
25 rpm*
|
✔
|
✔
|
** RPM : at 50Hz (Frequency)
